Description
DSE- MC-10
Rugged Micro Mission Computer
he Rugged Micro Mission Computer (MC-10) is a hardened stand-alone system that delivers powerful performance in a lightweight and miniature footprint. At less than 81in³ (6.7” x 4” x 3” including connectors) and 2lbs, this micro package is today’s solution for the mobile environment. Low power consumption, configuration flexibility, and cost efficiency make it an ideal solution for demanding applications in the military, industrial and commercial markets. Utilizing reliable Intel CPUs, the MC-10 has a robust I/O including digital video, (2) gigabit ethernet, (4) USB 2.0, (2) RS-232/RS-485, HD Audio, and GPIO. Designed with modularity in mind, the MC-10 can be customized with application specific expansion capabilities such as 1553, ARINC 429, CANBus, GPS, additional comm or GPIO ports, and video frame grabbers. The MIL-SPEC design ensures operability in environmental conditions as defined per MIL-Standards 461, 704, 810, 1275, 3009, and DO-160.
Key Standard Features:
- Gigabit Ethernet Ports (2), 10/100/1000 Mbps
- 128GB Removable SSD^ (Optional 256GB,512GB or 1TB
- I/O Expansion Slots
- Display Port/Video Output, HDMI or DVI-D
- USB 2.0 Ports (4), RS-232/RS-485 Ports (2)
- Analog Audio Input/Output
- IP67/NEMA 6 Enclosure / Fully Sealed Enclosure
- -40°C to +71°C Operating Temperature
- Windows 10/ Linux Support
- MIL-Standards 461, 810, 704, 1275, and DO-160
Processor Features:
- Intel® Atom™ Quad Core*
- 91GHz
- 2MB Cache
- 4GB RAM (8GB available)
- 8GB EMMC Onboard Flash
- Real Time Clock
Additional Processor features available upon request.
| System I/O | (2) Gigabit Ethernet; (4) USB 2.0 Ports; (2) RS-232/RS-485 Ports; Analog Audio Input and Output; Display Port, HDMI or DVI-D |
| Processor | Intel Atom Quad Core, 1.91GHz |
| Operating System | Windows or Linux |
| Memory | Configurable |
| Storage | Removable mSATA Hard Drive; 128GB, 256GB, 512GB or 1TB |
| Housing | Milled Aluminum, Black Hard Anodized |
| Wide Range DC Power Input† | 28 VDC (18-33 VDC) (per MIL-STD-704, 1275) |
| Power Conditioning | Protected against Internal Short Circuit, Load Dump, Over Voltage and Reverse Polarity |
| Expansion Options | ARINC429, CANBus, GPS, GPIO, HD-SDI, RS170, USB |
